3 PC bride boul valv
Lachin ekipman pou 3 PC bride valv boul se depoze kò ak tij prèv blow-out. Li gen ISO 5211 pad aliye dirèk pou actuator. Manch plen twou ak bloke aparèy li yo disponib. Tou gen sele TEFLON pi bon kalite ak chèz.
Spesifikasyon
| Port | Port konplè | ||
| Plen pò | 1/2 "~ 4" (DN15 ~ DN100) | ||
| Kò WP | 1000 WOG (PN63) | ||
| Flange Fen WP | PN40 | ||
| W.T. | -20 degre ~200 degre (-4 degre F ~ 392 degre F) | ||
| Dimansyon bride | DIN 2501 - PN40 | ||
| Fas a fas | DIN 3202 - F1 | ||
| Aparèy fèmen |
ISO 5211 Montaj pad - 2010M (opsyon) ISO 5211 pad aliye dirèk - 2010D (opsyon) |
||
Tablo gwosè pwodwi yo
| ATIK | PATI | MATERYÈL |
| 1 | Etid | A2-70 (SS304) |
| 2 | Nwa | A2-70 (SS304) |
| 3 | Machin pou lave prentan 1 | A2-70 (SS304) |
| 4 | Kò valv | CF8% 2fCF8M (SS304% 2fss316) |
| 5 | Boul | CF8% 2fCF8M (SS304% 2fss316) |
| 6 | Syèj | PTFE |
| 7 | Kaskèt | CF8% 2fCF8M (SS304% 2fss316) |
| 8 | Manch kouvèti | Plastik |
| 9 | Manch | Asye pur |
| 10 | Gland nwa | CF8 (SS304) |
| 11 | Tij | CF8M (SS316) |
| 12 | Tij nwa | A2-70 (SS304) |
| 13 | Machin pou lave prentan 2 | A2-70 (SS304) |
| 14 | Anwo anbalaj | PTFE |
| 15 | Anba anbalaj | PTFE |
| 16 | Tij sele | PTFE |
Dimansyon (mm)
| Gwosè (pous) | ΦA | ΦB | ΦC | ΦD | E | f | n-Φd | L1 | L±1.5 | H |
| 1/2" | 15 | 45 | 65 | 95 | 14 | 2 | 4-Φ14 | 107 | 130 | 73 |
| 3/4" | 20 | 58 | 75 | 105 | 16 | 2 | 4-Φ14 | 107 | 150 | 75 |
| 1" | 25 | 68 | 85 | 115 | 16 | 2 | 4-Φ14 | 142 | 160 | 88 |
| 1 1/4" | 32 | 78 | 100 | 140 | 16 | 2 | 4-Φ18 | 142 | 180 | 93 |
| 1 1/2" | 38 | 88 | 110 | 150 | 16 | 3 | 4-Φ18 | 203 | 200 | 102 |
| 2" | 50 | 102 | 125 | 165 | 18 | 3 | 4-Φ18 | 203 | 230 | 110 |
| 2 1/2" | 65 | 122 | 145 | 185 | 18 | 3 | 4-Φ18 | 223 | 290 | 117 |
| 3" | 80 | 138 | 160 | 200 | 20 | 3 | 8-Φ18 | 300 | 310 | 127 |
| 4" | 100 | 158 | 180 | 220 | 20 | 3 | 8-Φ18 | 350 | 350 | 144 |
Avantaj pwodwi yo
1. 3 PC bride boul tiyo yo dirab, fè byen apre anpil sik, ak serye, fèmen byen menm apre peryòd long nan inutilize.
2. Kalite sa yo fè yo yon chwa ekselan pou aplikasyon pou fèmen, kote yo souvan pi pito pou valv pòtay ak glòb, men yo manke kontwòl amann yo nan aplikasyon pou throttling.
3. Gen aparèy anti-estatik sou boul ak kò. anjeneral ranje tanperati a se<150° C . We have 100% leakage tested at 100 psi air under water.
Poukisa chwazi Hebei Cucheng
Nou fè fas sitou nan ekspòtasyon an nan klou asye, vis, Fastener, fil asye ak may fil, kloti asye, tiyo metal, ekipman tiyo, tiyo, sistèm echafodaj, pwofil asye ak pwodwi aliminyòm.
Mache prensipal nou yo enplike Inyon Ewopeyen, Mwayen ak Amerik di Sid, Azi Sidès, Mwayen Oryan ak Lafrik.
Nou angaje nan kontinyèlman inovasyon pwodwi nou yo, bay kliyan etranje ak yon gwo kantite bon jan kalite pwodwi depase satisfaksyon kliyan yo.
